3252 - pneumatic - ANSI

Globe valve

VALVE STYLE
Globe valve

USAGE

  • Throttling service
  • On/off service
  • High-pressure service

VERSION
ANSI

MEDIUM TEMPERATURE
-200 to 450 °C / -328 to 842 °F

SUPPLY
Pneumatic

VALVE SIZE
NPS ½ to NPS 1
G ½ to G 1
½ NPT to 1 NPT

PRESSURE RATING
Class 300 to Class 2500

LINING
without

Special features

  • Consisting of high-pressure valve in globe or angle style with pneumatic actuator
  • Valve body and wetted parts of stainless steel
  • Welding ends, weld-on flanges, G or NPT threaded connections

Accessories

  • Type 2 N Strainer
  • Type 2 NI Strainer

Options

  • Insulating section or bellows seal
  • Adjustable packing
  • Heating jacket

3252 - pneumatic - ANSI can be combinated with the following actuations:

Special features:

  • Single-acting linear actuator with rolling diaphragm and internal springs
  • Diaphragm areas from 120 to 2x2800 cm²
  • Low overall height
  • Powerful thrust at high stroking speed
  • Low friction
  • Various bench ranges by varying the number of springs or their compression
  • No special tools required to change the bench range or reverse the direction of action (also version with handwheel)

Special features:

  • Single-acting linear actuator with rolling diaphragm and internal springs
  • Diaphragm areas from 120 to 750 cm²
  • Direct attachment of accessories on additional yoke with concealed travel pick-off
  • Low overall height
  • Powerful thrust at high stroking speed
  • Low friction
  • Various bench ranges by varying the number of springs or their compression
  • No special tools required to change the bench range or reverse the direction of action (also version with handwheel)

Information

  • T 8053

    Type 3252-1 and Type 3252-7 Pneumatic Control Valves
    Type 3252 High-pressure Valve
    [EN][DE]
  • T 8000-6

    Information sheet
    Packings for Globe Valves
    Packing forms and their application ranges
    [EN][DE]
  • T 8000-1

    Information Sheet:
    Electric and Pneumatic Control Valves
    Series 240 · 250 · 290 · Series V2001 · PFEIFFER
    [EN][DE]
  • T 8000-2

    Information Sheet:
    Electric and Pneumatic Control Valves
    Series 240 • 250 • 290 • SAMSON PFEIFFER
    Materials and pressure-temperature diagrams
    [EN][DE]

Support

  • H 02

    Appropriate Machinery Components for SAMSON Pneumatic Control Valves with a Declaration of Conformity of Final Machinery
    [EN][DE]

DXF file from data sheet
